WALLS Mental Health Assessment Platform

Note: This is a standalone web implementation with the same ML model architecture. For the mobile version of this project, contact sks17@outlook.com.

Overview

WALLS is a Flask + PyTorch mental health screening platform with a local demo mode (CSV storage) and optional Firebase authentication. The system provides survey-based screening for stress, anxiety, and depression, using machine learning inference to generate predictions and metrics displayed through interactive dashboards.

The platform is designed to work both online (with Firebase) and offline (with local CSV storage), making it ideal for demonstrations, presentations, and deployments where cloud dependencies may not be available.

Features

Assessments + Inference

• Survey-based screening flow (stress/anxiety/depression)
• PyTorch model inference using the included ml/model.pt
• Prediction history + metrics endpoints for dashboards

Dashboard + Visuals

• 2D charts via Chart.js (loaded via CDN)
• 3D visual components via Three.js
• Refresh + persistence (history/metrics backfilled from storage)

Demo Mode (Offline)

• No Firebase required
• Local CSV persistence under user_data/demo/
• Seed script for consistent presentation data

Optional Firebase

• Firebase Admin + Firestore when credentials are present
• Falls back to local store when unavailable (demo-friendly)

Architecture

At a high level:

1. Browser loads Flask-rendered templates (templates/) and static JS (Static/js/)
2. Frontend calls API endpoints under /api/v2/* for predictions, history, and metrics
3. Backend runs inference through ml/ and stores results via services/user_store.py:
   • Firestore when configured
   • CSV demo store when not

The system is structured to support both cloud and local deployments:

• Frontend: Flask templates + vanilla JavaScript
• ML Layer: PyTorch for mental health assessment inference
• Visualization: Chart.js for 2D charts, Three.js for 3D components
• Backend: Flask API with RESTful endpoints
• Storage: Dual-mode storage (Firebase Firestore or local CSV)
• Authentication: Optional Firebase Auth with demo fallback

Most interactions happen through the API layer, with the frontend making requests for predictions, historical data, and aggregated metrics.

See It In Action

Build & Development

Prerequisites

• Python 3.12.x
• pip
• (Optional) Node.js if you’re touching the Firebase/FullCalendar frontend packages

Quick Start

# From the repo root
pip install -r requirements.txt
python app.py

App runs at http://127.0.0.1:5000 by default.

Demo Mode (Offline)

This is the fastest “works everywhere” path.

# Seed demo data (creates/updates CSVs)
python init_demo_data.py

# Start the server
python app.py

Notes:

• Demo data persists in user_data/demo/*.csv
• In demo mode, any login is treated as the same effective demo user

Example credentials (if you want something consistent for demos):

• Email: demo@example.com
• Password: demo1234

Environment Variables

Copy the template and edit:

Copy-Item env.example.txt .env

Minimum for local dev:

Variable	Required	Description
SECRET_KEY	Yes	Flask session/signing key
FLASK_ENV	No	development recommended
FLASK_DEBUG	No	true for debug
PORT	No	Default 5000

Firebase (optional): see env.example.txt for the full set.

Common Endpoints

• GET /api/v2/status – API status
• POST /api/v2/predict – run inference
• GET /api/v2/history – recent evaluations
• GET /api/v2/metrics – aggregate metrics for dashboard

Project Structure

WALLSAI/
├── app.py                      # Flask entrypoint
├── src/
│   └── api.py                   # /api/v2/* endpoints
├── api/                         # additional API blueprint(s)
├── services/
│   ├── user_store.py            # storage abstraction (Firestore or local demo store)
│   └── local_store.py           # CSV-backed demo store
├── ml/
│   ├── model.py                 # model definition
│   ├── preprocess.py            # feature prep
│   └── model.pt                 # trained weights
├── templates/                   # Flask templates
├── Static/
│   ├── js/                      # dashboard + survey + API client JS
│   └── images/
└── user_data/
    └── demo/                    # demo CSVs (evaluations/profiles/notes)

Technical Implementation

The core of WALLS is built around a flexible storage abstraction that allows the same codebase to work both online and offline. The services/user_store.py module provides a unified interface that automatically switches between Firestore and local CSV storage based on available credentials.

The machine learning pipeline uses PyTorch with a trained model (ml/model.pt) that processes survey responses through preprocessing layers before generating predictions. The model architecture is designed to be lightweight and fast, with inference typically completing in under 100ms.

The frontend visualization layer combines multiple libraries:

• Chart.js for standard 2D charts (line graphs, bar charts, histograms)
• Three.js for 3D visual components (when enabled)
• FullCalendar for timeline and scheduling features

All API endpoints follow RESTful conventions and return JSON responses. The /api/v2/* namespace provides versioned endpoints for future compatibility.

Notes for Contributors

• Keep demo mode working (no Firebase required) to support offline demos
• Prefer changes that keep /api/v2/history and /api/v2/metrics stable, since the dashboard relies on them
• Test both Firebase and local storage modes when making storage-related changes
• Follow the existing code structure for new API endpoints

What This Is For

WALLS exists to provide accessible mental health screening through a web interface that works anywhere, with or without cloud infrastructure. By supporting both online and offline modes, the platform can be demonstrated, tested, and deployed in a wide range of environments.

The dual-mode architecture makes it particularly useful for:

• Academic presentations and demos
• Healthcare settings with privacy restrictions
• Development and testing environments
• Deployments in areas with limited connectivity
